PMT Overbraced wall jib crane

Overbraced wall jib crane with IPE European I-beam sliding girder system.

PMT steel IPE European I-beam specifications

Capacity Span
2,5m 3m 3,5m 4m 4,5m 5m 5,5m 6m 6,5m 7m 7,5m
150 kg
250 kg
500 kg
1000 kg
1600 kg
2000 kg

Steel PMT overbraced wall jib crane

Steel PMT overbraced wall jib crane are economical solutions for equipping workplaces with a wall or pillar. IPE European I-beam sliding girder system manufactured, the steel overbraced wall jib crane has the double benefit to be both robust and light. It allows loads rotation through 180° and can be equipped with a motorized steering hoist (optional).

PMTC Hollow-profile steel overbraced wall jib crane

The 180° rotating hollow-profile steel overbraced wall jib crane can be equipped with either a manual or electric hoist and gives a great flexibility during operations. Equipped with an electric hoist (optional), it allows a maximum lifting speed of up to 16 m/min. The PMTC is supplied as standard:

  • a pre-installed power supply line
  • a hoist trolley mounted on plastic rollers

This overbraced wall jib crane cannot be motorized. It is suitable for indoor use only. It can only be moved by manually pushing the load.

PMTC Hollow-profile aluminium overbraced wall jib crane

The 180° rotating hollow-profile aluminium overbraced wall jib crane is easy to use due to its lightweight sliding girder system. Equipped with an electric hoist (optional), it allows a maximum lifting speed of up to 16 m/min. The PMTC is supplied as standard:

  • a pre-installed power supply line
  • a hoist trolley mounted on plastic rollers
  • bracket polyurethane RAL 1028 yellow finish

This overbraced wall jib crane cannot be motorized. It is suitable for indoor use only. It can only be moved by manually pushing the load.

Toolholder PMTL Hollow-profile aluminium overbraced wall jib crane

Ergonomic and durable, The lightweight hollow-profile aluminium overbraced wall jib crane is an ideal accessory for tools hanging and moving through your indoor workshops. You can move tools by manually pushing over an area of 180° around its axis. Do not use this overbraced wall jib crane for lifting loads but tools.

The PMTL is supplied as standard:

  • polyurethane RAL 1028 yellow finish
  • standard mounting brackets

The PMTL is compatible our special anchor kits.

Overbraced wall jib crane standard equipments

  • standard mounting brackets
  • polyurethane RAL 1028 yellow finish

Overbraced wall jib crane options

  • Special anchoring kit
  • Hoist power supply cable + lockable main switch
  • Standpipe
  • Rotating slowing device (adaptable without mechanical or welding intervention)
  • Hot dip galvanizing (please contact us)
  • Rotation stops to weld onto the assembly
  • Locking rotation device 1 or multiposition
  • Outdoor use
  • Electric or manual hoist (except PMTL)

Conformity

Our PMT underbraced wall jib crane are provided with a CE conformity Certificate
